XGN2 13.8KV 2000A 2500A High Voltage Power Distribution Switchgear

Basic Information
Place of Origin: XIAN, China
Brand Name: XG
Certification: ISO CCC
Model Number: HXGN...
Minimum Order Quantity: 1 SET
Packaging Details: WOODEN CASE
Delivery Time: 7-15 DAYS
Payment Terms: L/C, T/T, D/A, D/P, L/C, Western Union, MoneyGram
Supply Ability: 500 SET
Detail Information
Function: Control Or Protection Installation Location: Power Systems
Warranty: 12 Months OEM: Yes
Package: Exporting Wooden Case Or Customized MOQ: 1set
Life Span: More Than 15 YEARS Working Temperature: -45℃ To +40℃
High Light:

XGN2 Power Distribution Switchgear

,

2500A Power Distribution Switchgear

,

XGN2 Vacuum Switchgear Panel


Product Description

1. XGN2 type 10kv 11KV 13.8KV 1250A 2000A 2500A high voltage vacuum switchgear panel



11kv fixed GIS switchgear is a complete set of power distribution devices for 3.5kV ~ 12kV with three-phase AC 50Hz single bus ,single busbar with bypass system or dual bus system for power receiving and transmission.

11kv fixed GIS switchgear can meet the request for all kinds of power plants, substations or mining and industrial enterprises. This switchgear is indoor device, which can be equipped with various models of the main circuit breaker, with the features of double-sided maintenance, and vertical self-stand installation, it is especially for frequent operation occasions.



2. Product specification OF high voltage vacuum switchgear panel



Item(Unit) Data
Rated Voltage(kV) 3.6, 7.2, 12
Rated Current(A) 630-3000
Rated Frequency(Hz) 50
Rated Short-time Power Frequency Withstand Voltage(kV) 18,23,42
Rated Lightning Impulse Withstand Voltage(kV) 40,60,75
Rated Peak Withstand Current(kA) 63,80,100
4S Rated Short-time Withstand Current(kA) 25,31.5,40
Standard GB3906
Protect Degree IP2X



3. Product application OF high voltage vacuum switchgear panel



Altitude:≤1000m;

Daily average temperature(Within 24h): ≤+35℃

Ambient air temperature : -5°C ~ +40°C;

Relative humidity: winthin 24h, daily average value ≤ 95% , daily average vapor pressure≤ 2.2KPa; monthly average value ≤90%, monthly average vapor pressure≤ 1.8KPa



4. Photo and drawing of high voltage vacuum switchgear panel



XGN2-12 图纸.jpg





5. Fatory strength of high voltage vacuum switchgear panel



XGN2 13.8KV 2000A 2500A High Voltage Power Distribution Switchgear 1



6. Delivery diversifition



XGN2 13.8KV 2000A 2500A High Voltage Power Distribution Switchgear 2



7. FAQ



1. Send the technical data, better for all useful information; we will make a good recommendation.

If possible please attach one reference picture to avoid any misunderstanding or any links from our website for we get a better understanding.

2. The lead time depend on quantity of order. Some standard type is on stock. Otherwise, it will take 3-15 days.

3. Usually shipped by sea, small order or urgent order we can send you by air.

4. All our activities are accredited to ISO 14001:2015 and IEC standard.
