GN22 Outdoor 11KV 12KV Isolator High Voltage Disconnect Switch

Basic Information
Place of Origin: XIAN,CHINA
Brand Name: XG
Certification: ISO,CCC
Model Number: GN22
Minimum Order Quantity: 1 SET
Packaging Details: WOODEN CASE
Delivery Time: 7-15 DAYS
Payment Terms: L/C, T/T, D/A, D/P, Western Union, MoneyGram
Supply Ability: 2000 SET
Detail Information
System Voltage: 11kv 12kv System Current: 630a-2500a
Working Temperature: -45℃ To +40℃ Life Span: 15 YEARS
Operation Type: Electric Or Manual Phase: 3
Pole: 3 Pole Installation Location: Power Plants, Substations
High Light:

GN22 High Voltage Disconnect Switch

,

11KV High Voltage Disconnect Switch

,

XG High Voltage Disconnect Switch


Product Description



1. GN22 Type Outdoor 11KV 12KV Isolator High Voltage Disconnect Switch



GN22-12(C) disconnect switch is an indoor electric apparatus of rated voltage 12kV three-phase AC 50/60Hz. it is used to break, make and transfer lines when the HV apparatus is under situations with voltage and no-load. It is manufactured according to IEC62271-102.



2. Parameter Data of GN22 Isolating switch



(1).GN22 isolating switch is used for isolating the power that breaks the high voltage maintenance equipment from electrical equipment for maintenance.

(2). Isolation switch is equipped with circuit breaker which needs to reverse operation in order to change the system operation connection mode.

(3). GN22 is used to connect or break a small current circuit.

No. Item Unit Data
1 Rated voltage KV 12
2 Max working voltage (KV) V 12.7
3 Rated current A 1600-3150A



3. Product feature of GN22 Isolating switch



Ambient temperature: -25℃ ~+40℃ ;

Relative humidity: daily average ≤95%, monthly average ≤90%;

Altitude:≤1000m

Earthquake intensity: ≤8degree;

Applicable occasions should free from inflammables, explosives, corrosives and severe vibration.



4. Detailed drawing of GN22 Isolating switch








5. Factory



GN22 Outdoor 11KV 12KV Isolator High Voltage Disconnect Switch 3



6.  FAQ



1. Send the technical data, better for all useful information; we will make a good recommendation.

2. The lead time depend on quantity of order. Some standard type is on stock. Otherwise, it will take 3-15 days.

3. Usually shipped by sea, small order or urgent order we can send you by air.

4. All our activities are accredited to ISO 14001:2015 and IEC standard.
