Name: XRNM 3.6KV 7.2KV 10KV 12KV 40.5KV HRC Fuse For Motor Protection
Brand: Xi'an Xigao Electricenergy Group Co., Ltd.
SKU: XRNM
Price: 6.00 USD
Availability: InStock

XRNM 3.6KV 7.2KV 10KV 12KV 40.5KV HRC Fuse For Motor Protection

Basic Information

Place of Origin:	XIAN,CHINA
Brand Name:	XG
Certification:	ISO,CCC
Model Number:	XRNM

Minimum Order Quantity:	3 SET
Price:	USD3-10
Packaging Details:	WOODEN CASE
Delivery Time:	7-15 DAYS
Payment Terms:	L/C, D/A, D/P, T/T
Supply Ability:	10000 SET

Get Best Price Contact Now

Detail Information

Rated Voltage:	3.6KV 7.2KV 10KV 24KV 25KV	Rated Frequency:	50HZ/60Hz
Breaking Capacity:	50KA	Color:	White, Brown
Phase:	Single	Life Span:	15 YEARS
PROTECTION:	Motor Protection	Condition:	Original & New
Highlight:	10KV HRC Fuse , 12KV HRC Fuse , 40.5KV HRC Fuse

Product Description

1. XRNM type 3.6KV 7.2KV 10KV 12KV 40.5KV HRC Fuse for motor protection

XRNM type 3.6KV 7.2KV 10KV 12KV 40.5KV HRC Fuse for motor protection

1. Technical Data

Type	Rated Voltage/kV	Rated Current/A	Rated Breaking Current/kA
XRNM1-3 WDF.0	3.6	50,63,80,100,125	50
XRNM1-3 WFF.0		125,160,200
XRNM1-3 WKF.0		250,315,355,400	31.5
XRNM1-6 WFN.0	7.2	25,31.5,40,50,63,80,100,125,160	40
XRNM1-6 WKN.0		200,224,250,315
XRNM1-10	10	25,31.5,40,50,63,80,100,125,160,200,224

2.Standards

GB1984
GB/T28001-2011 idt OHSAS18001:2007
GB/T24001-2004 idt ISO14001:2004
GB15166.2
IEC282-1

3. Drawing

XRNM 3.6KV 7.2KV 10KV 12KV 40.5KV HRC Fuse For Motor Protection 0

4. Factory

XRNM 3.6KV 7.2KV 10KV 12KV 40.5KV HRC Fuse For Motor Protection 1

5. Delivery

XRNM 3.6KV 7.2KV 10KV 12KV 40.5KV HRC Fuse For Motor Protection 2

6. FAQ

1. Send the technical data, better for all useful information; we will make a good recommendation.

If possible please attach one reference picture to avoid any misunderstanding or any links from our website for we get a better understanding.

2. The lead time depend on quantity of order. Some standard type is on stock. Otherwise, it will take 3-15 days.

3. Usually shipped by sea, small order or urgent order we can send you by air.

4. All our activities are accredited to ISO 14001:2015 and IEC standard.

5. Technology ensure the quality satisfy international request.

Tag:

XRNM 3.6KV 7.2KV 10KV 12KV 40.5KV HRC Fuse For Motor Protection

10KV HRC Fuse

12KV HRC Fuse

40.5KV HRC Fuse

H.V. Current Limiting Fuse,

CCC HRC Fuse,

ISO HRC Fuse
